S.NO	NAME OF THE LABORATORY	YEAR/SEMESTER	ROOM Description	Lab Area In Sq.mts	Description /Usage
1	ELECTRONICS CIRCUITS AND DEVICES (EDC) LABORATORY /ECA LABORATORY	II-Year/ISemester & II-Year/IISemester	303	150	Academic lab and useful for Minor projects also
2	SWITCHING THEORY AND LOGIC DESIGN (STLD) LABORATORY	II-Year/I-Semester	323-A	100	Academic lab and useful for Minor projects also
3	ANALOG/ DIGITAL COMMUNICATION LAB	II-Year/II-Semester & III-Year/I-Semester	321-A	150	Academic lab and useful for Minor projects also
4	DIGITAL IC DESIGN (DICD) LABORATORY	II-Year/II-Semester	303	100	Academic lab and useful for Minor projects also
5	LINEAR IC’S APPLICATIONS (LICA) LABORATORY	III-Year/I-Semester	323-B	100	Academic lab and useful for Minor projects also
6	MICRO PROCESSOR AND MICRO CONTROLLER (MPMC) LABORATORY	III-Year/I-Semester	322-A	100	Academic lab and useful for Minor projects also
7	DIGITAL SIGNAL PROCESSING LABORATORY	III-Year/II-Semester	324	100	Academic lab and useful for Major Projects
8	VLSI LABORATORY	III-Year/II-Semester	426-A	100	Academic lab and useful for Major Projects
9	MICROWAVE ENGINEERING & OPTICAL LABORATORY	IV-Year/I-Semester	322-B	100	Academic lab and useful for Minor projects also
10	PROJECT LABORATORY	IV-Year/II-Semester	321-C	65	Research Projects, Major Projects, and Minor Projects
11	IOT LABORATORY	IV-Year/I-Semester	426-A	100	Academic lab and useful for Research Projects, Major Projects, and Minor Projects

S.NO	NAME OF THE ITEM	NAME OF THE COMPANY SUPPLIED	NO. OF USER’S
1	MAT LAB 8.2 PART NO ML	CAPRICOT TECHNOLOGIES Pvt.Ltd.	30
	MAT LAB 8.2 PART NO SL SIMULINK		05
	SIGNAL PROCESSING TOOL BOX		05
	IMAGE PROCESSING TOOL BOX		05
	DSP SYSTEM TOOL BOX		05
	CONTROL SYSTEM TOOL BOX		05
	COMMUNICATION SYSTEM TOOL BOX		05
	MATLAB Part No: ML		05
	DSP System Toolbox Part No: DS		02
	Deep Learning Toolbox Part No: NN		02
	Fuzzy Logic Toolbox Part No: FL		02
	Signal Processing Toolbox Part No: SG		02
	Statitistics and Machine Learning Toolbox Part No: ST		02
2	MULTISIM SOFT WARE	ASCENTRONICS SYSTEMS Pvt.Ltd.	25
3	Xilinx VIVADO	CoreEl Technologies Pvt.ltd	25
	MENTOR GRHAPICS HEP1		50
	ARTIX7 FPGA BOARDS		02
4	MENTOR HEP2 FRONT END	CoreEl Technologies Pvt.ltd	50
